Slide 074 — SED and MED

Clean FRCS notes with inline figures

Short stature

•SED

•Gene: COL2A1 on chromosome 12 (same gene as Kniest syndrome)

•Types

•Congenita: onset at birth, AD inheritance

•Tarda: onset >5yo, XL recessive

•Clinical

•General: disproportionate short stature, short trunk

•Face: hypertelorism, cleft palate

•Chest: pectus carinatum

•Limbs: coxa vara, genu valgum, equinovarus

•Spine: kyphoscoliosis, odontoid hypoplasia → AADI

XR:

•Hip dysplasia + coxa vara +/- genu valgum

•Platyspondyly

•Odontoid hypoplasia

CXR: restrictive lung disease

•MED

•AD

Gene:

•Type 1 COMP (Protein for cartilage mineralization. Mutation causes increase in proteoglycan in chondrocyte)

•Type 2 COL9A2

•Present in early adolescent

•Clinical

•General: disproportionate short stature, short limb

•Limbs: coxa vara, genu valgum, ankle valgus, acromelia (short digits)

•Spine: N

•IQ normal

XR

•Immature: small, flattened fragmented epiphysis

•Mature: flattening of WB joint + incongruity +/- early OA

•Double layered patella

Direct Q&A

Q1 What are the radiographic findings for SED and MED?

Hip dysplasia + coxa vara +/- genu valgum

•Platyspondyly

•Odontoid hypoplasia

Q2 How is SED and MED managed?

•Type 1 COMP (Protein for cartilage mineralization. Mutation causes increase in proteoglycan in chondrocyte)

•Type 2 COL9A2

•Present in early adolescent

•Clinical

•General: disproportionate short stature, short limb

•Limbs: coxa vara, genu valgum, ankle valgus, acromelia (short digits)

•Spine: N

•IQ normal

XR

•Immature: small, flattened fragmented epiphysis

•Mature: flattening of WB joint + incongruity +/- early OA

•Double layered patella
